SECTION 5 - CYLINDER
3121825 3369LE/4069LE/M3369/M4069 135
FIGURE 5-4. LEVELING JACK CYLINDER ASSEMBLY (USA BUILT MACHINES) (ORIGINAL
EQUIPMENT) (SN 0200112735 through 0200214444)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Note: Original Equipment Cylinder may have been replaced
with Service Replacement Cylinder. Identify p/n stamped on
cylinder before ordering parts.
1684291 Ref LEVELING JACK CYLINDER ASSEMBLY D
1 0100011 AR Compound, Locking
2 0100035 AR Compound, Locking
3 1120108 1 Cap, End
4 1681283 1 Head
5 1683967 1 Barrel, Cylinder
6 1684206 1 Rod, Cylinder
7 2220883 2 Plug
8 3300465 1 Locknut -1/4in-12NC
9 3480279 1 Piston
10 3573513 1 Plate
11 3760460 2 Ring, Retaining
12 3900321 3 Screw, Special 1/2in-13NC x 1-1/4in
13 4640495 1 Valve, Counter Balance
13 2900770 1 Seal Kit - 4640495 Valve
14 4641156 1 Valve, Check
14 2900770 1 Seal Kit - 4641156 Valve
15 4713000 1 Flatwasher 1-1/4in
16 4846584 1 Pad, Jack
101 See Note 1 Ring, Wear (Note: use p/n 2902264)
102 See Note 2 Ring, Wear (Note: use p/n 2902264)
103 See Note 1 O-Ring (Note: use p/n 2902264)
104 See Note 1 O-Ring (Note: use p/n 2902264)
105 See Note 1 Seal, Wiper (Note: use p/n 2902264)
106 See Note 2 Polyseal (Note: use p/n 2902264)
107 See Note 1 Seal, Piston (Note: use p/n 2902264)
Ref KIT OPTIONS:
200 2902264 1 Seal Kit (Includes Items 101-107)
