Page 247
13-7
Item
Part No.
Qty.
Description Of Part
9108-5047
Ref
AUXILIARY HYDRAULIC ASSY
(includes all items)
1
9112-6026
1
HANDLE WELDMENT
2
9112-6025
1
LEVER BRACKET
3
9112-6027
1
PIN WELDMENT
4
9020-0299
1
KNOB
5
8820-1036
4
HEX HD CAPSCREW, 3/8-16 x 1-1/4,
GR5
6
8850-1006
4
HEX NUT, 3/8-16
7
8855-1011
4
LOCKWASHER, 3/8
8
9108-3136
2
BUSHING
9
9002-8662
2
WAVE BEND WASHER
10
9103-3417
1
AUXILIARY CONTROL DECAL
11
9108-3420
1
MAIN CONTROL VALVE
12
8471-8026
2
HOSE ASSY
13
9108-3310
2
ELBOW, 90 DEGREES
14
8882-1002
1
ADJUSTABLE YOKE END
15
8863-3001
1
YOKE PIN, 1/4
16
8863-1302
1
COTTER PIN, 1/16 x 3/4
17
8850-1404
1
HEX JAM NUT, 1/4-28
18
9112-6023
1
CABLE BRACKET WELDMENT
19
9020-7464
2
CUSHION CLAMP
20
9112-3050
1
PUSH-PULL CABLE
21
9002-7187
10
TIE WRAP
22
8866-1065
2
UNION, 1/2 TUBE
23
8859-1206
2
O-RING
24
9112-3062
1
CABLE ADAPTER BONNET
Item
Part No.
Qty.
Description Of Part
25
9108-3343
2
LONG ELBOW, 90 DEGREES
26
8866-1348
2
TUBE END REDUCER, 5/8 x 1/4
27
8866-1407
2
NUT, 5/8
28
8820-1018
2
HEX HD CAPSCREW, 5/16-18 x 3/4,
GR5
29
8855-1010
2
LOCKWASHER, 5/16
30
8850-1005
1
HEX NUT, 5/16-18
31
9020-7463
4
CUSHION CLAMP
32
8856-1004
2
FLATWASHER, 3/8
33
9104-3125
1
DUST PLUG
34
9108-3290
1
HOSE CARRIER
35
8841-1037
4
ROUND HD CARRIAGE BOLT, 5/16-18 x 1
36
8852-1205
4
HEX LOCKNUT, 5/16-18
37
8471-7563
2
HOSE ASSY
38
9002-7179
4
90 DEGREE BULKHEAD FITTING
39
9020-6194
AR
TRIM-LOCK
40
1440-2248
AR
ADHESIVE
41
9020-6199
13"
TRIM-LOCK
42
9112-3061
2
BULKHEAD FITTING
43
8871-2305
2
REDUCING BUSHING, 1/2 x 1/4
44
9020-4244
1
MALE HYDRAULIC COUPLER
45
9020-4245
1
FEMALE HYDRAULIC COUPLER
46
8471-8032
2
HOSE ASSY
47
9104-3126
1
DUST CAP
48
7713-3139
1
STAUFF CLAMP SET
49
7713-3140
1
STAUFF COVER PLATE
50
7713-3177
1
HEX HD CAPSCREW,5/16-18 x 1 3/8
PCN 910289, 950078 MB
OPTIONAL EQUIPMENT
(9108-5047) Auxiliary Hydraulics
Starting Serial No. 0177005
Original Issue 12-90
Revised 11-14-97
ARTWORK ON PREVIOUS PAGE
* Changed part number on item 11, changed part number and
location on items 32, 33 & 47.
