Gradall 524 Parts Manual - Manual (Page 244)

39
43 45
46
11
38
35
42
44
47
(#16)
15 AMP
FUSE
IGNITION-START
SWITCH
B
I
A
S
ACC-C
GND-3
FUEL
GAUGE
LIGHT
VOLTMETER
LIGHT
ENGINE
TEMP
GAUGE
LIGHT
OIL
GAUGE
LIGHT
ACC-C
(#12)
RELAY
(#12)
(#16)
30 86
85 87A 87
(#12)
(#16)
15 AMP
FUSE
STOP
LIGHT
SWITCH
DOME
LIGHT
SWITCH
GND-5
REV
REV
-B
(#16)
FROM REV SWITCH
FWD/REV VALVE
BACK-UP
ALARM
TAIL
LIGHT
(BLACK)
STOP
LIGHT
(RED)
BACK-UP
LIGHT
(GREEN)
REAR
TAIL LIGHT
ASSEMBLY
FRONT
WORK
LIGHT
FRONT
WORK
LIGHT
WORK
LIGHT
SWITCH
15 15
ON
OFF
BEACON
OFF
ON PULL ON
LIGHTS AUX
LIGHT
HIGH
OFF
LOW
HEATER OFF
ON
STARTING AID
HORN
0 0 0 0 0 0
4X2
4X4
ALT 4X4
ON
OFF PARK BRAKE
PARK BRAKE ON
DATCON
HOURS 1/10
ACC-C
GND-3
TO
L.H.FR
T CAB LIGHT
TO
R.H.FR
T
CAB LIGHT
TO
REAR
TA
IL LIGHT
86 30
87
RELAY
85
TO STOP LIGHT SWITCH
TO DOME LIGHT
IGN
ACC
ACC BAT
BA T
IGN
ST
PARTIAL VIEW FROM ABOVE DASH
ELECTRICAL SCHEMATIC
Item Part No. Qty. Description Of Part
9108-5103 1 WORK LIGHT PACKAGE, (includes
all items)
1 8096-3050 2 UTILITY FLOOD LIGHT
2 9114-1182 1 R.H. LIGHT SUPPORT
3 9114-1183 1 L.H. LIGHT SUPPORT
4 9105-3419 AR TIE WRAP
5 8820-1035 2 HEX HD CAPSCREW, 3/8-16X1, GR5
6 8856-1109 2 FLAT WASHER, 3/8
7 8855-1011 2 LOCKWASHER, 3/8
8 8850-1006 2 HEX NUT, 3/8-16
9 9002-7319 4 TAP SCREW, 1/4-20X1
10 8688-3260 2 EYELET
11 9114-3270 1 LIGHT HARNESS
12 8668-3122 AR TIE WRAP
13 9002-7214 8 RUBBER GROMMET
14 9101-1009 1 MOUNTING BRACKET
15 9002-9955 1 RUBBER GROMMET
16 8832-1022 2 SELF TAPPING SCREW, #8-32X3/8
17 2486-1167 1 INTERIOR LIGHT
18 8096-3055 3 W. PACK CONNECTOR, (tower)
19 8096-3056 3 W. PACK CONNECTOR, (shroud)
20 8096-3068 3 W. PACK CONNECTOR, (female pin)
21 8096-3069 9 W. PACK CONNECTOR, (male pin)
22 8096-3066 12 W. PACK CONNECTOR, (cable seal)
23 9020-7220 1 MOUNTING BAR
24 9112-1145 1 TAIL LIGHT HOUSING
25 9112-1146 1 TAIL LIGHT BRACKET
26 9136-5045 2 TAIL LIGHT ASSEMBLY, (includes the
following seven items)
Item Part No. Qty. Description Of Part
9112-3065 1 TAIL LIGHT
8666-1147 38" WIRE, 16 GAUGE, (black)
8666-1149 38" WIRE, 16 GAUGE, (green)
8666-1152 38" WIRE, 16 GAUGE, (red)
8668-3480 3 BUTT CONNECTOR
8203-3996 45" WIRE LOOM
8668-3122 2 TIE WRAP
27 8820-1018 2 HEX HD CAPSCREW, 5/16-18X3/4,
GR5
28 8856-1108 2 FLAT WASHER, 5/16
29 8855-1010 2 LOCKWASHER, 5/16
30 8096-3058 1 W. PACK CONNECTOR, (shroud)
31 7738-3410 1 RELAY
32 8832-1039 1 SELF TAPPING SCREW, #10-32X1/2
33 9114-1364 1 JUMPER WIRE
34 9114-3210 1 TAIL LIGHT HARNESS
35 9114-1266 1 JUMPER WIRE
36 AR WIRE LOOM, (use on all wires)
37 8096-3062 1 W. PACK CONNECTOR, (shroud)
38 9114-1265 2 JUMPER WIRE
39 7736-3268 2 FUSE, 15 AMP
40 9114-1197 1 MOUNTING TAB
41 9114-3117 1 STOPLIGHT SWITCH
42 7738-3467 1 LIGHT SWITCH
43 9114-3108 2 FUSE HOLDER
44 7738-3470 1 BOOT
45 9103-3360 4 GUAGE LIGHTING KIT
46 9114-1258 1 JUMPER WIRE
47 9114-1259 2 JUMPER WIRE
PARTIAL VIEW FROM UNDER DASH
OPTIONAL EQUIPMENT
(9108-5103) Work Light Package
Starting Serial No. 0177122
Original Issue 12-95
Revised 9-29-00
13-5 PCN 000221-SVC * Revised illustration and parts list.
