Ethernet Flash Memory Upgrade
49
14.1 Uploading the Applet
After upgrading a unit's firmware, the Java Applet has to be manually
re-uploaded to preserve remote access via a Web-browser. The Java Applet
data file can be found on the disc or on our Web site at
To upload the applet to the unit via the Kramer RC Configuration:
Follow these steps to install the Web Applet:
1. Connect RC device to your PC through computer networking:
2. Start RC Configuration Software and connect to the RC device (see section
3. In the Device menu select Upgrade Applet option and browse to the MC.dat
file included in the package:
4. Wait until uploading is complete
5. Click OK.
and the success message appears.
1 This section is relevant only for units with an Ethernet connector
2 The product's built-in Java Applet may take a few minutes to load
