The Kramer RC Configuration Main Window
24
9 The Kramer RC Configuration Main Window
Once the drivers are imported and the ports are defined, use the Kramer RC
Configuration main window to assign a sequence of commands (the macro)
for each RC button.
Figure 23 illustrates the Kramer RC Configuration main
window, and Table 5 defines it:
Figure 23: The Kramer RC Configuration Main Window
Table 5: Kramer RC Configuration Window Features
# Feature Function
1 Menu Bar Menus are described in section 11
Device Area
2 Name Box Displays the name of the specific device
1
3 Connection Box Displays the connection properties with the device (IP address and
port)
1
4 Type Display Box Select the device type
2
5
.
Change… Button Press the Change… to change the device type (from a list)
1 The name and IP number are initially set by the Device Selection dialog box (see section 11.4 )
2 The device type can be selected only if there is no device connected to the computer. If a device is connected, the device
type is selected automatically
