The Kramer RC Configuration Main Window
26
# Feature Function
Button Macro Area
13 Button Macro Display Box Displays the macro RC commands’ Description, Delay and Port in
sequence. Select an RC command to duplicate, delete, or change its
position in the sequence
New Command Button Click to add a new command to the Button Macro display box
1
(see
section 10 )
Duplicate Command Button Duplicate a command in the Button Macro display box
Delete Command Button Delete a command from the Button Macro display box
Button
Move up the selected command
Button
Move down the selected command
14 RC command Area Includes the following features of the command selected in the
Button Macro display box:
Description Text Box Optional descriptive text for the command
Port Drop Down Box Displays the port associated with the RC command:
Select a port when modifying or writing a new RC command.
When selecting an IR port, a serial port, or an Ethernet port, the
Vendor, Device, Revision and Driver command drop down boxes
appear, as well as the Port default driver box and an Update button to
update the port default driver. The command bytes box appears for the
serial and Ethernet ports.
When selecting a relay port, the Relay command drop down box
appears.
Vendor Drop Down Box Displays the current vendor. Select the vendor when writing a new
RC command or modifying a selected command
Device Drop Down Box Displays the device driver name. Select the device driver when
modifying or writing a new RC command
Revision Drop Down Box Displays the device driver revision. Select a revision when modifying
or writing a new RC command
Driver command Drop Down
Box
Displays the current driver command. Select a driver command
when writing a new command or modifying a selected command
Relay command Drop Down Box Select the Relay command:
Open – N.C. and Common are connected (default)
Close – N.O. and Common are connected
Port default driver Box and
Update Button
The port default driver box shows the current port default driver. It can
be updated by setting a different driver through the RC command and
then clicking the Update button (see section
8 )
Command bytes Box Displays the command bytes
15 Button lighting Area
2
Select the buttons that will illuminate, turn dark or remain the same
following a command (the lighting configuration can be different for each
command within the sequence). Toggle between ON (yellow), OFF
(black) and No Change (gray). You can also click reset to reset the
buttons to No Change (gray)
16 Delay after command Text Box
2
Set a delay time in seconds or milliseconds following the command
3
1 The button macro display box displays under Description and None under Port
.
The delay between the commands can be set from 0.01 seconds up to
640 seconds. Also, multiple commands with delays can be cascaded to
create a longer delay, if required, up to about 2.5 hours (15 delays of 10
minutes each).
2 Shows after checking this option in the configuration menu (see section 11.3 )
3 In seconds or milliseconds, via check box
