The Kramer RC Configuration Menus
42
11.3 The Configuration Menu
Figure 4 illustrates the Configuration menu and 4 Table defines it: 8
Figure 44: The Configuration Menu
Table 8: Configuration Menu Features
Menu Command Function
Port Manager Lists the ports names,
description, settings and drivers
(see section
8 )
Show Delay Check to show in RC main
configuration window
Show Button
Lighting
Check to show in RC main
configuration window
Show Response
Querying
Check to show in RC main
configuration window
11.4 The Device Menu
Figure 4 illustrates the Device menu and 5 Table defines it: 9
Figure 45: The Device Menu
Table 9: Device Menu Features
Menu Command Function
Discover… Click to open the Device
Selection window and search for
connected devices (see section
11.4.1 )
Connect… Click to connect via an IP
number or serial port
Disconnect Click to disconnect the device
Properties…
1
Click to show the device
properties dialog
Write Configuration
1
Writes the configuration to the
device
Read Configuration
1
Reads the configuration from
the device
Upgrade Applet
1
Upload a Java applet
Lock Panel
1
Click to lock the front panel
buttons on the device
Unlock Panel
1
Click to unlock the front panel
buttons of the device
1 Active only when a device is connected via the Ethernet
