Kramer Electronics RC-8iR - Manual (Page 18)

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting to the RC Device
14
6.2 The “Connect” Connection Method
To connect the RC device to your PC via the Connect connection method, do
the following:
1. Connect the RC device to the PC via either of the following:
 Ethernet port (see section
10.3 )
 Serial CONFIG serial configuration jack 1
2. Select the connection method to:
 Ethernet (
Figure 9 ), and enter the IP address
 Serial Port (
Figure 1 ), and enter the select the PC serial port to which
the RC machine is connected
0
Figure 9: The Connection Method – via the
Ethernet
Figure 10: The Connection Method – via
the Serial Port
3. Click OK.
1 Via the CONFIG cable (C-A35M/D9F-6) from the CONFIG port to the serial port on a PC for devices that do not have an
Ethernet connector (for example, the RC-7BE)
