Creating a Macro
34
10.2.3 The IR Command –Audio Follows Video in a Matrix Switcher
To add an IR command to the macro, do the following:
1. Open the Kramer RC Configuration window.
2. Select the RC button to which you want to add the command.
3. In the Description text box, type the new command’s description (for example,
Audio Follows Video).
4. From the Port drop down box, select the desired IR port
1
5. From the Command drop down box, select the relevant command (for
example, AFV).
(for example, IR_1).
Figure 34 shows the IR command setting:
Figure 34: IR Command Setting
1 Once the port is selected, the default driver details appear
