Connecting to the RC Device
13
6 Connecting to the RC Device
Table 3 defines the connecting ports available for each machine and the
connecting methods:
Table 3: Machine Connection Method
The Machine Name The Connection Port The Connection Method
RC-8IR, RC-8IRE Ethernet, RS-232 Discover (see section 6.1 )
Connect (See section 6.2 ) RC-6IR, RC-6IRE
RC-6IRP, RC-8IRP
RC-8RK, RC-8RKL
VP-23RC
RC-7B, RC-7BE 3.5mm Serial
configuration Jack
Connect (See section 6.2 )
RC-7LC, RC-7LCE
RC-7RL, RC-7RLE
6.1 The “Discover” Connection Method
To connect the RC device to your PC via the Discover connection method, do
the following:
1. Connect the RC device to the PC via the Ethernet port, as described in section
10.3 .
2. Click the appropriate shortcut in the Start menu’s Programs folder.
The Kramer RC Configuration main window opens.
3. Open the Device menu and click Discover
1
4. The Device Selection dialog box lists the devices found, and their IP number
(see
.
The Device Selection window opens.
Figure 8 ). Select the device and then click OK.
Figure 8: Connecting a Device to your PC – Device Selection Dialog Box
1 To automatically search for devices
