Creating a Macro
37
10.3 Connecting via the ETHERNET
You can connect the RC device via the Ethernet, using a crossover cable (see
section
10.3.1 ) for direct connection to the PC or a straight through cable (see
section 10.3.2 ) for connection via a network hub or network router.
10.3.1 Connecting the ETHERNET Port Directly to a PC (Crossover Cable)
You can connect the Ethernet port of the RC device to the Ethernet port on your
PC, via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the factory default
IP Address of the RC device (192.168.1.39) during the initial configuration
After connecting the Ethernet port, configure your PC as follows:
1. Click to open your Network Connections or right-click the My Network Places
icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears (see Figure 37 ).
Figure 37: Local Area Connection Properties Window
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 37 ).
6. Select Use the following IP Address, and fill in the details as shown in
Figure 38 .
