Technical Specifications
49
10 Technical Specifications
Table 12 includes the technical specifications:
Table 12: Technical Specifications of the VS-3232V Video Matrix Switcher
INPUTS: 32 composite video, 1Vpp / 75 on BNC connectors
OUTPUTS: 32 composite video, 1Vpp / 75 on BNC connectors
VIDEO BANDWIDTH: >300MHz, -3dB / >50MHz, 0.1dB
ALL HOSTILE CROSSTALK: <-49dB @5MHz
NON LINEARITY <0.2%
VIDEO S/N: 70dB unweighted / 78dB @5MHz weighted
DIFF. GAIN: <0.15%
DIFF. PHASE: <0.08 Deg.
K-FACTOR: <0.05%
CONTROL: 19 pushbutton switches; RS-232, RS-485, IR remote, Ethernet
SWITCHING: 3 modes for Vertical interval switching and Immediate switching
DIMENSIONS: 19-inch (W), 7-inch (D) 2U (H) rack-mountable
POWER SOURCE: 230 VAC, 50/60Hz, (115VAC, U.S.A.) 10VA
WEIGHT: 3.5kg (7.8 lbs.) approx
ACCESSORIES: Power cord, Null modem adapter, Windows®-based Kramer control
software, Windows®-based Ethernet Configuration Manager and Virtual
Serial Port Manager, Infra-red remote control transmitter
11 Communication Protocols
Using the menu, you can select between the:
Kramer 2000 communication protocol (see section 11.1), or
ASCII Protocol (see section 11.2)
11.1 The Kramer 2000 Communication Protocol
Table 13 and Table 14 include the Protocol 2000 1 hexadecimal codes 2 . The
communication parameters are: 9600 baud, with no parity, 8 data bits and 1
stop bit.
1 Full details are available on our Web site: www.kramerelectronics.com
2 This example assumes MACHINE # 1, and node 0
