Connecting the Video Matrix Switcher
17
6.3.1
Setting the MACHINE #
To control a unit remotely via RS-232, RS-485, IR or the Ethernet, each unit
has to be identified via its unique Machine #. Set the Machine #
1
on a
VS-3232V unit according to Table 4.
Table 4: Machine # Dipswitch Settings
Mach. #
DIP 1
DIP 2
DIP 3
DIP 4
Mach. #
DIP 1
DIP 2
DIP 3
DIP 4
1
ON
OFF
OFF
OFF
9
ON
OFF
OFF
ON
2
OFF
ON
OFF
OFF
10
OFF
ON
OFF
ON
3
ON
ON
OFF
OFF
11
ON
ON
OFF
ON
4
OFF
OFF
ON
OFF
12
OFF
OFF
ON
ON
5
ON
OFF
ON
OFF
13
ON
OFF
ON
ON
6
OFF
ON
ON
OFF
14
OFF
ON
ON
ON
7
ON
ON
ON
OFF
15
ON
ON
ON
ON
8
OFF
OFF
OFF
ON
6.3.2
Understanding the System Mode
Though the terms audio-follow-video
2
and audio breakaway
3
are well known,
there may be signals other than audio signals that need to be switched
simultaneously and at other times, need to be switched independently.
For example:
Non-linear editing systems that combine video with analog audio or with
digital audio
Duplication systems, that produce Master tapes from programs with
different formats such as composite analog, component analog and
component digital
The term FOLLOW-SYSTEM
4
indicates the most common case where
any type of signal can follow one or more other signals.
DIP 5 defines whether the
VS-3232V unit can communicate with other
switchers via a common control line.
You
can set DIP 5 OFF to disable the FOLLOW-SYSTEM mode when
setting a standalone switcher
5
application, including standalone multi-
channel video switcher applications
6
.
1 When using a single unit, set the unit to MACHINE # 1
2 Video and the audio channels switch simultaneously in the same way
3 Audio channels switch independently from the video channels
4 Instead of Audio-Follow-Video
5 See section 6.1
6 See section 6.2
