The MENU Commands
39
The configuration menu includes the following items:
SYNC configuration (see section 8.1)
INTERFACE configuration (see section 8.2)
Interface REPLY configuration (see section 8.3)
PROTOCOL configuration (see section 8.4)
DEFAULT setup configuration (see section 8.5)
Store DEFAULT setup (see section 8.6)
Indication of the current Firmware version (see section 8.7)
TOTAL RESET options (see section 8.8)
8.1 Selecting the SYNC Configuration
Table 6 summarizes the SYNC configuration options:
Table 6: SYNC Configuration Menu
Press: To select: After the change, the LCD displays:
1 NoVIS , for immediate switching The unit is set for immediate switching
2 INT#1 , SYNC extracted from input #1 Active SYNC set from input #01
3 EXT-BNC , SYNC extracted from
GENLOCK input
Active SYNC set from GENLOCK input
4 EXT-SYS , SYNC received from another unit Active SYNC set from another unit
8.2 Selecting the INTERFACE Configuration
The INTERFACE configuration menu is a two step menu:
1. Select the type of interface.
2. Turn the interface ON or OFF.
Note that the RS-232 interface is always ON.
Table 7 summarizes the INTERFACE configuration options.
Table 7: INTERFACE Configuration Menu
Press: To select: After the change, the LCD displays:
1 RS485 Interface RS-485 now active or, interface RS-485 now off
2 IRremote IR remote now active or, IR remote now off
3 Ethernet Network connection now active or network connection now off
