Connecting the Video Matrix Switcher

6.2.3

Configuring a 32x32 RGBS Switcher (Four Units)

Configure four

VS-3232V switchers as a 32x32 video matrix switcher for

RGBS

, in a similar way to how Figure 5 in section 6.2.2 illustrates combining

three VS-3232V switchers for YUV (RGB).

6.3 Dipswitch Settings

Configure the

VS-3232V by setting the eight dipswitches as Figure 6 and

Table 3 define:

RS-232 NULL-MODEM

MACHINE #

SYSTEM MODE SLAVE MODE

RS-485 TERMINATION

Figure 6: Dipswitches

Table 3: Dipswitch Definitions

Dipswitch #

Function:

1-4

Set the MACHINE # (see Table 4 in section 6.3.1)

Enables (ON) or disables (OFF) the FOLLOW

SYSTEM

MODE in a multi-switcher

configuration

Enables (ON) or disables (OFF) the

SLAVE

mode

in a multi-channel configuration

Disables the use of a null modem adapter

with RS-232 as follows:

Set OFF for RS-232 input connection via a null modem adapter

Set ON for RS-232 input connection without a null modem adapter

Set ON for RS-485 termination for the first and the last machine (RS-485 line

terminates with 110 ); for others set OFF (RS-485 line is open)

1 The S signal must be composite video SYNC (analog), not TTL
2 See section 6.4.1
