Operating Your Video Matrix Switcher
32
7.4.3 Switching one Input to all Outputs
To switch one input to all the outputs (in the At Once mode):
1. Press the MENU button once.
The Menu buttons 1 illuminate and are enabled.
2. Press the illuminated ALL button.
The LCD display shows the message:
// 01
3. Press the appropriate digit buttons (for example, 09 representing input 9).
All the outputs switch to this input. The LCD display shows all the outputs
switched to the input 9.
To switch all the outputs to one input in the Confirm mode (the TAKE LED is
illuminated), repeat the steps above and then press the blinking TAKE button
to confirm the action.
7.4.4 Clearing an Output
To clear an output (in the At Once mode):
1. Press the MENU button once.
The Menu buttons 1 illuminate and are enabled.
2. Press the illuminated OFF button.
The LCD display shows the message:
// 01
3. Press the appropriate digit buttons (for example, 25 representing output 25).
This output is cleared (there is no input switched to this output).
To clear an output in the Confirm mode (the TAKE LED is illuminated), repeat
the steps above and then press the blinking TAKE button to confirm the action.
Alternatively, you can perform a switching operation as described in
section7.4.1 and set the input to 00.
7.4.5 Clearing several Outputs
To clear several outputs in the Confirm mode (the TAKE LED is illuminated),
repeat the switching actions described in section 7.4.2 but set all the inputs to 00:
7.4.6 Clearing all Outputs
All the outputs can be cleared only through the configuration menu (see
section 8.8).
1 The ALL, OFF, STO and RCl buttons
