KRAMER: SIMPLE CREATIVE TECHNOLOGY
The MENU Commands
40
8.3 Selecting the Interface REPLY Configuration
Table 8 summarizes the interface REPLY configuration options:
Table 8: Interface REPLY Configuration Menu
Press:
To select:
After the change:
1
Turn reply ON
All the interfaces that are set to ON accept and execute commands and also reply
2
Never REPLY
All the interfaces that are set to ON accept and execute commands but do not reply
8.4 Selecting the PROTOCOL Configuration
Table 9 summarizes the PROTOCOL configuration options:
Table 9: PROTOCOL Configuration Menu
Press:
To select:
After the change, the LCD displays:
1
HEXadecimal
, for setting the protocol
1
to
HEX KRAMER-2000
Communication protocol set to HEX KRAMER-2000
2
ASCII
, for setting the protocol
1
to ASCII –
SIERRA
Communication protocol set to ASCII – SIERRA
8.5 Selecting the DEFAULT Setup Configuration
Table 10 summarizes the DEFAULT setup configuration options:
Table 10: DEFAULT Setup Configuration Menu
Press:
To select:
After the change, the LCD Displays:
1
Setup+crosspoints
Store/recall DEFAULT MATRIX setup and cross-points
2
crosspnts
Store/recall DEFAULT ONLY cross-points
3
setups
Store/recall DEFAULT only MATRIX setup
8.6 Selecting the store DEFAULT Setup Configuration
This option in the configuration menu lets you store the current setup to the
default setup, so that by pressing the DEFAULT SETUP button on the front
panel you can recall the default setup (so called UNITY setting).
After pressing the ENT button, the TAKE button blinks and the following
message appears on the display:
$
:
<4
9
After pressing the blinking TAKE button, the display shows:
$
:
5
1 See section 11 for a description of the protocols
