Operating Your Video Matrix Switcher
28
7 Operating Your Video Matrix Switcher
This section describes:
The startup display (see section 7.1)
How to use the selector buttons (see section 7.2)
How to confirm actions (see section 7.3)
The switching options (see section 7.4)
How to store and recall setups (see section 7.5)
The DEFAULT SETUP button (see section 7.6)
How to Choose the FOLLOW or the BREAKAWAY modes (see
section 7.7)
How to Lock and unlock the front panel (see section 7.8)
7.1 Startup Display
After switching on the power, the LCD display
1
shows the following screens
in sequence:
!
"# $ "#
%
$
&&&
'(
'#
'"
')
'*
'+
',
'-
'.
('
((
(#
("
'(
'#
'"
')
'*
'+
',
'-
'.
('
((
(#
("
Figure 13: Default Startup Status Display Sequence
The
VS-3232V does not have separate output and input pushbuttons. Instead,
the front panel includes a numerical keyboard within the Selector Buttons
area
2
. This keyboard that includes the numbers from 0 to 9, lets you enter both
the output and input numbers.
1 The text in the LCD Display may vary (according to machine settings)
2 See Table 1
