Connecting the Video Matrix Switcher
11
6 Connecting the Video Matrix Switcher
You can install the VS-3232V as:
A composite video standalone switcher (see section 6.1)
An s-Video switcher, by combining two VS-3232V switchers: one unit for
the Y signal and the second unit for the C signal (see section 6.2.1)
A component video (YUV/RGB) switcher, by combining three VS-3232V
units: one for the Y signal, the second for the U signal and the third for the
V signal (see section 6.2.2)
An RGBS switcher, by combining four VS-3232V units: one for the R
signal, the second for the G signal, the third for the B signal and the fourth
for the SYNC (see section 6.2.3)
6.1 Connecting the VS-3232V as a Composite Video Switcher
To install the VS-3232V as illustrated in the example in Figure 3, do the
following 1 :
1. Connect up to 32 composite video sources (for example 2 , two composite
video players).
2. Connect up to 32 composite video acceptors (for example 2 , two displays).
3. Set the dipswitches (see section 6.2.3).
4. If required, connect a PC and/or controller to the RS-232 port (see
section 6.4.1) and/or the RS-485 port (see section 6.4.2) and/or the
ETHERNET port (see section 6.6).
5. Connect the power cord 3 .
6. If necessary, review and set the system variables, using the MENU function,
and the default setup (UNITY setting) as section 8 describes.
1 Switch OFF the power on each device before connecting it to your VS-3232V
2 In this example only two inputs and two outputs are connected
3 We recommend that you use only the power cord that is supplied with this machine
