MX410/MX412 System Manual Menu Descriptions
61189500L1-1B PRELIMINARY 5-31
MAC Address This read-only field displays the Medium Access Control (MAC)
Address. MAC Addresses are location-independent (programmed
into the card at manufacture, they relocate when the card does).
MAC Addresses are contained in the headers of packets and are
used to filter and forward packets.
Eth (1-4)
3 Link Speed & Duplex This option invokes another menu which is used to select the data
rate setting for Ethernet Port (1-4) on the front panel of the
MX410/MX412. Options are as follows:
• 1 - Auto
• 2 - 10 Mbps, Half Duplex
• 3 - 10 Mbps, Full Duplex
• 4 - 100 Mbps, Half Duplex
• 5 - 100 Mbps, Full Duplex
N/A Functional Link
Speed & Duplex This read-only field displays the actual data rate of the port.
N/A Link Status This read-only field displays the status of the network as being
either Up or Down.
Table 5-15. Ethernet Menu Options (Continued)
Option Description Function
