Figure 1-2. mx412 overview -3 – ADTRAN MX410 User Manual
Page 15
MX410/MX412 System Manual
Product Overview
61189500L1-1B
PRELIMINARY
1-3
Figure 1-2. MX412 Overview
4 x 10/100 Ethernet
FXS
4 x RS-232
E911, etc.
Digital Radios Data
Analog Radios Data
Grooming of DS0S
LAN Extension over PPP for Remote Management
Star Configuration of Backhaul
Backhaul
12 x T1
V.35
Battery Backup
HVAC
Backhaul Radio Management
(I/O)
DB-9 Craft Interface
