Menu Descriptions

MX410/MX412 System Manual

5-24 PRELIMINARY

61189500L1-1B

The Cross-Connect Mapping menu options are shown in

Table 5-10

Table 5-10. Cross-Connect Mapping Menu Options

Option

Description

Function

1-24

DS0 1-24 connections

These options invoke the Change Cross-Connect Mapping menu
which is used to provision the cross-connect settings for the
selected DS1 port. Options are as follows:

• 1. Choose TO Group (for DS1 1 through DS1 4/DS1 12)
• 2. Choose TO DS0: (enter a value)
• 3. Robbed Bit Signaling: select Enabled or Disabled
• 4. Apply Cross-Connect: applies the selections made from the

Change Cross-Connect Mapping menu.

Map Multiple DS0's

This option invokes the Change Cross-Connect Mapping menu
which is used to provision the cross-connect settings for multiple
DS0s at the same time. Options are as follows:

• 1. Choose FROM DS0 Range: enter a range
• 2. Choose TO Group (for DS1 1 through DS1 4/DS1 12)
• 3. Choose TO DS0 Range: enter a range
• 4. Robbed Bit Signaling: select Enabled or Disabled
• 5. Apply Cross-Connect: applies the selections made from the

Change Cross-Connect Mapping menu to all DS0s in the
range entered.

Cross-Connect Mapping - Ports

PPPs

This option invokes the Change Cross-Connect Mapping menu,
which is used to provision the PPP ports. Options are as follows:

• 1. Choose FROM PPP (for PPP 1 through PPP 4)
• 2. Choose TO Group (for DS1 1 through DS1 4)
• 3. Choose TO DS0 Range: enter a range
• 4. Apply Cross-Connect

V.35

This option invokes the Change Cross-Connect Mapping menu,
which is used to provision the V.35 port. Options are as follows:

• 1. Choose TO Group (for DS1 1 through DS1 4/DS1 12)
• 2. Choose TO DS0 Range: enter a range
• 3. Apply Cross-Connect

FXS (MX412 only)

This option invokes the Change Cross-Connect Mapping menu
which is used to provision the FXS port. Options are as follows:

• 1. Choose TO Group (for DS1 1 through DS1 12)
• 2. Choose TO DS0 Range: enter a range
• 3. Mode: Select Loop Start, PLAR D4, PLAR D3, or FX

Ringdown. Refer to

Table 4-6

on page 4-9 for descriptions of

these options.

• 4. Apply Cross-Connect
