ADTRAN MX410 - Manual (Page 62)

Menu Descriptions MX410/MX412 System Manual
5-12 PRELIMINARY 61189500L1-1B
Configuration Screen
The Configuration Screen (see Figure 5-5 ) displays information about the MX410/MX412.
Information such as Code Version changes as upgrades are performed. The CLEI Code and
Part Number can be used to search for related information on the ADTRAN website or to order
additional parts. Some information from this menu may be required when calling the ADTRAN
Technical Support.
Figure 5-5. Configuration Screen
The Configuration screen fields are shown in Table 5-3 .
MX410 MM/DD/YY HH:MM
Active Alarms: CRITICAL ID: MX410
Configuration
Unit Name : MX410
CLEI Code : M3M1310BRA
Part Number : 1189500L1
Serial Number : DVTUUTNXXX
Product Revision : B
MAC Address : XX:XX:XX:XX:XX:XX
Code Version : B01
Code Checksum : ADCDEFGH
Boot Version : B03
Boot Checksum : 7C22
'?' - System Help Screen
