10

Only use accessories and spare parts
which have been approved by the
KÄRCHER. The exclusive use of origi-
nal accessories and original spare parts
ensures that the appliance can be oper-
ated safely and troublefree.

At the end of the operating instructions
you will find a selected list of spare
parts that are often required.

For additional information about spare
parts, please go to the Service section
at www.kaercher.com.

The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.

We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.

5.957-914

The undersigned act on behalf and under
the power of attorney of the company man-
agement.

Authorised Documentation Representative
S. Reiser

Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212

Winnenden, 2012/03/01

Technical specifications

Operating voltage

V/~/Hz

220...240/1/50

Connected load

W

2000

Water input pressure
without carbonisation

MPa (bar) 0,15...0,6 (1,5...6)

with carbonisation, max.

MPa (bar)

0,15 (1,5)

Water supply temperature

°C

+4...+35

Water dispensed, max.
Uncooled water

l/h

100

Cooled water

l/h

24

Hot water

l/h

50

Temperature of hot water, max.

°C

85

Temperature of cooled water, max.

°C

5

Ambient temperature

°C

+5...+35

Width

mm

410

Depth

mm

460

Height without support leg

mm

410

Height with support leg

mm

1420

Weight
WPD 100 Standard without support leg

kg

33

WPD 100 Standard with support leg

kg

53

WPD 100 Top without support leg

kg

33

WPD 100 Top with support leg

kg

53

Sound pressure level during normal operation

dB(A)

<45

Hy Protect filter

Active pure filter

max. permissible media temperature

+ 40°C

+ 40°C

max. permissible operating pressure

0.6 MPa (6 bar)

max. flow performance

100 l/h

max. capacity

9,000 Liter

Materials / approvals

All water-bearing parts/components are suited and approved for the use in di-

rect contact with drinking water as mandated by the industry standard.

Spare parts

Warranty

EC Declaration of Conformity

Product:

Water Dispenser

Type:

1.024-xxx

Relevant EU Directives

2006/42/EC (+2009/127/EC)

2004/108/EC

Applied harmonized standards

EN 55014–1: 2006 + A1: 2009

EN 55014–2: 1997 + A2: 2008

EN 60335–1

EN 60335–2–75

EN 61000–3–2: 2006 + A2: 2009

EN 61000–3–3: 2008

Applied national standards

-

CEO

Head of Approbation

23

EN
