Using the Magnetic Encoding Tab – Custom Encoding or Raw Binary
Encoding Mode
You can change the Magnetic Track options for Tracks 1, 2 and 3 when using the Custom Encoding or
Raw Binary Encoding Mode. These options are not available for ISO or JIS II encoding.
Window TAB Procedure Procedure (continued)
Select No LRC to change the
LRC Generation to none.
Select Even Parity to change
the LRC Generation to Even
Parity. (Note: This is the default
for all tracks.)
Select Odd Parity to change
the LRC Generation to Odd
Parity.
Select No Parity to change the
Character Parity to none.
Select Even Parity to change
the Character Parity to Even
Parity.
Select Odd Parity to change
the Character Parity to Odd
Parity. (Note: This is the
default for all tracks.)
Reverse Bit Order is used to
reverse the character bits and is
used for the encryption of data
in specific programs Add Leading Zeros is used to
add a set number of leading
zeros to the magnetic string in
order to move the starting
point of the encoded data in
specific programs for
encryption of data.
