DTC4500 Card Printer/Encoder User Guide L001444 Rev1.1
11
Technical Specifications
Term Function
Print Speed
• 7 seconds per card (K*)
• 12 seconds per card (KO*)
• 24 seconds per card (YMCKO*)
• 31 seconds per card (YMCKOK*)
• Print speed indicates an approximate batch print speed and
is measured from the time a card feeds into the Printer to the
time it ejects from the Printer.
• Print speeds do not include encoding time or the time
needed for the PC to process the image.
Process time is dependent on the size of the file, the CPU,
amount of RAM and the amount of available resources at the
time of the print. Indicates the Ribbon type and the number of
Ribbon panels printed where Y=Yellow, M=Magenta, C=Cyan,
K=Resin Black, O=Overlay, F=Fluorescing Resin
Card Size and
Types Supported
• CR-80 (3.375"L x 2.1125"W / 85.6mmL x 54mmW)
• CR-79 (3.313”L x 2.063”W / 84.1mmL x 52.4mmW
Accepted Standard
Card Sizes
• CR-80 edge-to-edge (3.36"L x 2.11"W / 85.3mmL x
53.7mmW)
• CR-79 (3.3”L x 2.04”W / 83.8mmL x 51.8mmW)
Accepted Card
Thickness
• Print Only: .009” - .040” / 9 mil – 40 mil / .229mm –
1.016mm
• Print/Lamination: .030” - .040” / 30 mil – 40 mil / .762mm –
1.02mm
