DTC4500 Card Printer/Encoder User Guide L001444 Rev1.1
50
Selecting the Advanced Settings tab
Setting Option
Flipper Lam Height
Offset This is a calibration driven value and should not be
adjusted. If the Flipper unit is replaced and has not been
calibrated, this value may need to be adjusted.
(Note: This is factory set and should not be changed
unless directed by a technician.)
Mag HI-Co Voltage Offset This option changes the voltage going the magnetic head.
(Note: This is factory set and should not be changed
unless directed by a technician.)
Mag Lo-Co Voltage
Offset This option changes the voltage going the magnetic head.
(Note: This is factory set and should not be changed
unless directed by a technician.)
OLED Contrast
(display contrast)
Use this option to increase or decrease the contrast of the
printer OLED (if applicable).
Resin Heat Adjust Use this adjustment for Black resin text and barcodes Iif
they appear faded or too light/dark.
• Maximum Adjustment Range is +/- 100.
(Note: This control can be helpful for fine-tuning the
transfer of resin text and bar codes.)
Head Resistance This is factory set. If the main board or the Printhead is
replaced then adjust this number.
Locate the Printhead Setting Number on the bottom of the
Printhead.
The number reads R=XXXX.
