VertX Installation Guide
Introduction
HID’s VertX open platform is flexible and scalable to permit economic and high performance access control
solutions for a wide range of applications. The VertX units interconnect through different sub-networks and
protocols to a standard TCP/IP network with the capability of a variety of applications.
For example, the VertX Access Controllers are a cost-effective method for two-way communication using
Ethernet between a computer and a V1000 or V2000. In addition, the V1000 can communicate through a
RS-232 serial port and a multi-drop RS-485.
Parts List
Description Quantity
VertX™ units (one of the following):
V2000 (Reader Interface / Access Controller)
V1000 (Access Controller)
V100 (Door/Reader Interface)
V200 (Input Monitor Interface)
V300 (Output Control Interface)
Note: Each VertX unit has a plastic base and is covered with a Plastic or Mylar cover.
1 V2000
or
1 V1000 and
any combination of
(up to 32) interface
panels.
- Lithium Battery (V1000 / V2000) 1
- Mounting screws 4
- 2.2K EOL resistors 8 ea V1000/V2000
4 ea V100-Series
- Quick Installation Guide 1
- Installation Wiring Diagram Example 1
Note: One or more VertX Interface panels are required when installing a V1000 controller.
Note: A modem and RS-232 Serial modem cable must be purchased separately, if your installation includes a
modem.
Product Specifications
Description Specification
Power Supply 12-16VDC
Maximum Current at 12VDC per unit 1 Amp
V1000 -210mA
V2000 - 625mA (with two R40 iCLASS Readers)
V100 - 450mA (with two R40 iCLASS Readers)
V200 - 60mA
Average operating current at 12VDC
V300 - 75mA
Operating temperature range 32°-122°F (0°-50°C)
Humidity 5% to 95% non-condensing
