VertX Installation Guide
Input
number
V2000 V1000 V100 V200 V300
1
P2 Pins 1/2
Door Monitor
P14 Pins 1/2
P2 Pins 1/2
Door Monitor
P1 Pins 1/2 P6 Pins 2/1
2
P2 Pins 3/4
REX input
P11 Pins 4/3
P2 Pins 3/4
REX input
P1 Pins 3/4 P3 Pins 1/2
3
P5 Pins 4/3
Door Monitor
P7 Pins 8/7
Tamper
P5 Pins 4/3
Door Monitor
P1 Pins 5/6
P7 Pins 8/7
Tamper
4
P5 Pins 2/1
Rex Input
P7 Pins 6/5
AC Fail
P5 Pins 2/1
Rex Input
P1 Pins 7/8
P7 Pins 6/5
AC Fail
5
P7 Pins 8/7
Tamper
P7 Pins 4/3
Batt Fail
P7 Pins 8/7
Tamper
P1 Pins 9/10 P7 Pins 4/3
Batt Fail
6
P7 Pins 6/5
AC Fail
P7 Pins 6/5
AC Fail
P2 Pins 1/2
7
P7 Pins 4/3
Batt Fail
P7 Pins 4/3
Batt Fail
P2 Pins 3/4
8 P2 Pins 5/6
9 P4 Pins 10/9
10 P4 Pins 8/7
11 P4 Pins 6/5
12 P4 Pins 4/3
13 P4 Pins 2/1
14 P5 Pins 6/5
15 P5 Pins 4/3
16 P5 Pins 2/1
17
P7 Pins 8/7
Tamper
18
P7 Pins 6/5
AC Fail
19
P7 Pins 4/3
Batt Fail
December 2010 Page 11 of 24
