49

Chapter 8

AT-TS24T Connectivity

AT-TS24T Modules

The AT-TS24T has 24 10BASE-T ports incorporated in two Telco 50-pin
(RJ21) receptacles for UTP. Figure 47 shows the AT-TS24T faceplate; the
following section describes the Telco receptacle. For general information
about UTP wiring, see Appendix A.

Figure 47: AT-TS24T Faceplate

Port activity LED symbols

RJ21
connectors

Plastic door/handles
