TurboStack Hubs with Management

7

Chassis Options

ATI offers a variety of desktop and rackmount chassis. These chassis are
available with either standard or segmented backplane configurations.

Chassis with

Standard

Backplane

An ATI chassis equipped with a standard backplane can hold up to a
maximum of eight TurboStack hubs connected through the standard
backplane mounted in the inside back wall of the chassis.

Figure 3 shows ATI’s 8-slot chassis with fans and standard backplane.

Figure 3: 8-slot Chassis with

Standard Backplane

Standard

backplane
