27

Chapter 3

AT-TS06F/ST, SC, SM Connectivity

AT-TS06F/ST, SC, SM Modules

ATI offers three 6-port fiber optic hubs with management capability. The
only physical difference among the three models is the connector
attachment type. Table 5 lists the model numbers, port counts, and media
connector type for each.

Table 5: AT-TS06F Hubs with Management

The ST (Straight Tip) model has attachment points with two pins to
connect bayonet-style. The SC (Subscriber Channel) model has a square
push-pull mating interface. The SMA (Sub Miniature Assembly) model
has a threaded attachment for connection with the module port.

Model Number

Port Count

Media/Connector Type

AT-TS06F/ST

6

Fiber Optic (10BASE-FL) with Straight Tip (ST)
Connectors

AT-TS06/SC

6

Fiber Optic (10BASE-FL) with Subscriber Channel
(SC) Connectors

AT-TS06F/SM

6

Fiber Optic (10BASE-FL) with Sub Miniature
Assembly (SMA) Connectors
