Hardware Installation

18

You can combine any TurboStack hub model type with any of the six
network port appliqués listed in Table 3.

Table 3: ATI Network Port Appliqués

Note

In swapping appliqués, it is advisable to turn off power to the hub since you
will be loosening screws and installing metal parts through the appliqué
port. Loose metal parts can cause damage to the circuit boards and
components.

External

Transceivers

Another option is to configure the AUI network port for other media by
using an external transceiver. Table 4 lists the ATI micro transceivers
available for this purpose.

Table 4: ATI Micro Transceivers

Model

Description

AT-TSA1

SM/SMA Fiber Optic Port

AT-TSA2

SC Fiber Optic Port

AT-TSA3

ST Fiber Optic Port

AT-TSA5

AUI Port

AT-TSA8

BNC Port

AT-TSA9

RJ45 Port

Model

Description

AT-MX10/MX10S

Thin Ethernet (10BASE2), BNC Connector

AT-MX40F/ST

Fiber Optic (10BASE-FL), ST Connector

AT-MX50F/SM

Fiber Optic (10BASE-FL), SMA Connector

AT-MX55F/SC

Fiber Optic (10BASE-FL), SC Connector

AT-210T/210TS/MX20T

UTP (10BASE-T), RJ45 Connector
