37

Chapter 5

AT-TS12F/ST, SC, SM Connectivity

AT-TS12F/ST, SC, SM Modules

ATI offers three fiber optic managed hubs, each with twelve ports. The
only physical difference among the three models is the connector
attachment type. Table 6 lists the model numbers, port counts, and media
connector type for each.

Table 6: AT-TS12F Series Hubs with Management

The ST (Straight Tip) model has attachment points with two pins to
connect bayonet-style. The SC (Subscriber Channel) model has a square
push-pull mating interface. The SM (Sub Miniature Assembly) model has
a threaded attachment for connection with the module port.

Model Number

Port

Count

Media/Connector Type

AT-TS12F/ST

12

Fiber Optic (10BASE-FL) with Straight Tip (ST)
Connectors

AT-TS12F/SC

12

Fiber Optic (10BASE-FL) with Subscriber Channel (SC)
Connectors

AT-TS12F/SM

12

Fiber Optic (10BASE-FL) with Sub Miniature Assembly
(SMA) Connectors
