AT-TS06F/ST, SC, SM Connectivity

28

Figure 22, Figure 23 and Figure 24 show faceplates for each of the three
types of hub modules.

Figure 22: AT-TS06F/ST

Faceplate

6 ST connectors

Port activity LEDs

Module
handles/doors

AUI port

RS232 port

Network LEDs

Power receptacle

Figure 23: AT-TS06F/SC

Faceplate

6 SC connectors

Port activity LEDs
