47

Chapter 7

AT-TS12TR Connectivity

AT-TS12TR Modules

The AT-TS12TR has 12 10BASE-T ports represented by 12 RJ45
connectors for UTP. Figure 44 shows the AT-TS12TR faceplate; the
following section describes the connectors. For information about UTP
wiring, refer to Appendix A.

Figure 44: AT-TS12TR

Faceplate

RJ45
connectors

Port activity
LEDs

Plastic door/handles
