33

Chapter 4

AT-TS08 Connectivity

AT-TS08 Modules

The AT-TS08 SNMP-managed hub has eight 10BASE2 ports with BNC
connectors. Figure 29 shows the AT-TS08 faceplate; the following sections
describe the connectors in detail.

Ports 1 through 7 are standard 10BASE2 network ports, suitable for
connecting workstations or other network devices via 10BASE2 segments.

Figure 29: AT-TS08 Faceplate

BNC connectors
