TurboStack Hubs with Management

3

Three types of network management capability:

— SNMP
— Via ASYNC ASCII terminal port (Omega)
— Telnet (Omega)

Software upgrade through firmware cassette or in-band
downloading

Hot swapping of modules in chassis

Comprehensive diagnostic LED support

Storage of up to 300 addresses per hub module

Updates to the MAC address table are effected dynamically in
Learning Mode or manually by the user.

Inventory management through storage of multiple addresses on
MAC address table

Security feature to handle intrusions when secure mode locks MAC
address table

Hubs with

Management

Table 1 shows the various models of manageable TurboStack hubs with
management capability. You can mix any combination of these models in a
department concentrator chassis for maximum flexibility. Subsequent
chapters of this manual describe the individual model types in detail,
including faceplate design, connection type and LED displays.

Table 1: TurboStack Hubs with Management

Model Number

Port

Count

Media/Connector Type

AT-TS06F/ST

6

Fiber Optic (10BASE-FL) with Straight Tip (ST)
Connectors

AT-TS06F/SC

6

Fiber Optic (10BASE-FL) with Subscriber Channel(SC)
Connectors

AT-TS06F/SM

6

Fiber Optic (10BASE-FL) with Sub Miniature Assembly
(SMA) Connectors

AT-TS08

8

Thinnet (10BASE2) with Bayonet Nut Couple (BNC)
Connectors

AT-TS12F/ST

12

Fiber Optic (10BASE-FL) with Straight Tip (ST)
Connectors

AT-TS12F/SC

12

Fiber Optic (10BASE-FL) with Subscriber Channel (SC)
Connectors

AT-TS12F/SM

12

Fiber Optic (10BASE-FL) with Sub Miniature Assembly
(SMA) Connectors

AT-TS12T

12

UTP (10BASE-T) with Telco 50-pin (RJ21) Connector

AT-TS12TR

12

UTP (10BASE-T) with RJ45 Connectors

AT-TS24T

24

UTP (10BASE-T) with two Telco 50-pin (RJ21)
Connectors

AT-TS24TR

24

UTP (10BASE-T) with RJ45 Connectors
