Overview

4

Hubs without

Management

In addition to the TurboStack hubs with management, ATI offers six
models without management (i.e., Slave modules). When used in
conjunction with the managed hubs listed in Table 1, the TurboStack
Slave hubs become SNMP manageable. Table 2 details the specific model
number, port count and media/connector type available for these Slave
hubs.

Table 2: TurboStack Hubs without Management

Note

References in this manual to SMA and SM are interchangeable, both being
acronyms for Sub Miniature Assembly.

Attention

For additional information about the TurboStack slave hubs, refer to the
TurboStack™ AT-TS12FS/ST, SC, SM; AT-TS24TRS; AT-TS24TS Ethernet
Slave/Manageable Hubs Installation Manual
available on request through
your ATI sales reperesentative.

Wiring

Configuration

Rules

Depending on the medium you choose, there are certain wiring practices
you should follow to ensure the reliability of communication throughout
the network. TurboStack hubs comply with IEEE standards for 802.3
Carrier Sense Multiple Access with Collision Detection (CSMA/CD)
Ethernet; you should refer to these standards when implementing your
network. Some important guidelines for ensuring integrity in network
wiring appear in later chapters and the appendices of this manual.

Chassis Configuration

Department

Concentrator

You can use a single manageable TurboStack hub in standalone mode or
as part of a department concentrator housed in a chassis. Various chassis
models are available for desktop or rackmount configurations. These
include 1-, 2-, 3-, 4-, 7-, and 8-module combinations for desktop or 19-inch
rackmount installations with standard or segmented backplanes.

Model Number

Port

Count

Media/Connector Type

AT-TS12FS/SM

12

Fiber Optic (10BASE-FL) with Sub Miniature Assembly
(SMA) connectors

AT-TS12FS/SC

12

Fiber Optic (10BASE-FL) with Subscriber Channel (SC)
Connectors

AT-TS12FS/ST

12

Fiber Optic (10BASE-FL) with Straight Tip (ST)
Connectors

AT-TS24TS

24

Two 50-Pin Telco Connectors

AT-TS24TRS

24

24 RJ45 Connectors
