AT-S26 Version 2.0.1 User’s Guide
91
3. Select Add MAC address.
The Adding a Multicast Address window in Figure 40 is displayed.
Figure 40 Adding a Multicast Address Window
4. In the VLAN Name field, enter the name of the VLAN to receive the
multicast frames. Select Enter.
5. In the MAC Address field, enter the MAC address of the multicast
stream. Select Enter.
6. In the Ports for Multicast field, enter one or more port numbers that
are members of the specified VLAN and that are to receive the
multicast packets from the device. Select Enter.
You can use one of the following formats to specify the port numbers:
Single port (for example, 1)
Several ports separated by a comma (for example, 3, 5, 6)
Range of ports (for example, 2-4)
All ports by entering the word “all”.
You can combine these different formats in a single line.
A port can have more than one multicast address associated with it.
The number of multicast addresses you can configure is limited to ten
per switch.
Omega confirms a successful operation with the message MAC
address added and the MAC address.
7. Return to the Main Menu.
Add MAC Address Menu
MAC Addresses
MAC Address Multicast Packet Ports VLAN
VLAN Name: Default VLAN
MAC address: Null (not configured)
Ports for multicast Null (not configured)
(Example: 1,3,8-14, or all)
Return to Add MAC Address Menu ...
