Configuring the Ports
76
Configuring Port Security
The switch features two levels of port security that you can use to
enhance network security. These levels allow you to control network
access by limiting the number of MAC addresses that are learned on the
ports on the switch. The levels are as follows:
Limited - The ports will continue to learn new MAC addresses up to a
user defined maximum limit.
Secure - The ports will immediately stop learning new MAC addresses,
limiting network access only to those nodes whose MAC addresses have
already been learned.
Note
This port security feature does not apply to ports on any expansion
modules that might be installed in the switch.
To set the port security level for the ports on the switch, perform the
following procedure:
1. From the Omega Main Menu, select System Configuration.
The System Configuration menu in Figure 8 on page 43 is displayed.
2. Select Security/Source Address Table.
The following window is displayed:
Figure 28 Port Security Menu
3. Select the desired port security level. The levels are described below:
Automatic
This selection disables port security. With this option activated, the
switch will not restrict the number of MAC addresses that are learned
on the switch ports. This is the default setting.
Source Address Learning Mode:
> Automatic: source address learning enabled; no intruder protection
Limited: intruder protection when port MAC address limit exceeded
Secure: source address table locked; intruder protection enabled
Security object port ALL
Config MAC address limit per port
Return to System Configuration Menu ...
