Configuring Virtual LANs and Quality of Service
102
Creating a New Port-based or Tagged VLAN
This section contains the procedure for creating a new VLAN on a switch.
The procedure for creating a new VLAN consists of three phases:
❑ Phase 1:
— Name the VLAN.
— Assign a VLAN ID (VID) number to the VLAN.
— Designate which ports are to be members of the VLAN.
— Define which, if any, ports will be tagged ports.
❑ Phase 2:
— Remove the untagged ports from existing VLANs.
❑ Phase 3:
— Change the PVID of the untagged ports in the new VLANs to
match the VID.
The AT-9006 Series Gigabit Switches have one default VLAN, called
Default VLAN. The Default VLAN is assigned a VLAN ID. All the ports on
the switch are initially port-based (untagged) members of the Default
VLAN with a PVID of 1.
To create a new VLAN, perform the following procedures.
Phase 1
To perform Phase 1, do the following:
1. From the Omega Main Menu, select Virtual LANs/QoS.
The Virtual LAN/QoS menu in Figure 44 is displayed.
Figure 44 Virtual LAN/QoS Menu
Virtual LAN Menu
Virtual LAN definitions
Port to VLAN configuration
Assign Port Priority
Priority Weight configuration
Assign Management Port to VLAN
Return to Main Menu ....
