AT-S26 Version 2.0.1 User’s Guide
43
Setting IP
Parameters
To set the IP parameters for the switch using the Omega management
interface, perform the following procedure:
1. From the Omega Main Menu, select System Configuration.
The System Configuration menu shown in Figure 8 is displayed.
Figure 8 System Configuration Menu
2. Select IP Parameters.
The IP Parameters window shown in Figure 9 is displayed.
Figure 9 IP Parameters Window
System Configuration Menu
System name Null (not configured)
Default Aging Time 300
Omega Options
IP parameters
Security / Source Address Table
Terminal configuration
System Switch configurations
Return to Main Menu ...
IP address: 0.0.0.0
Subnet mask: 0.0.0.0
Gateway address: Null (not configured)
Domain Name Server: Null (not configured)
Default Domain Name: Null (not configured)
Manager address: Null (not configured)
Manager address: Null (not configured)
Manager address: Null (not configured)
Manager address: Null (not configured)
DHCP configuration:
Download Password:
*****
Config Download Password: ******
Get community string: public
Set community string: private
Trap community string: public
Location: Null (not configured)
Contact: Null (not configured)
Return to System Configuration Menu ...
