Configuring the MAC Address Table
86
Static MAC Address Table
The static MAC table contains a list of the MAC addresses that have been
entered manually. You can use the table to specify the MAC addresses of
devices that are connected to ports that might not be learned via the
dynamic learning process of the switch. Entering static MAC addresses
ensures that certain devices have access to the switch ports, because
aging time, power failures, or switch resets do not affect the static MAC
table. Each switch maintains its own static address table.
Displaying the
Static MAC
Address Table
To display the static address table for a switch, perform the following
procedure:
1. From the Omega Main Menu, select MAC Address Table.
The MAC Address Table menu in Figure 30 is displayed.
2. Select All static MAC addresses.
The screen displays previously-added static MAC addresses, their
ports, and the VLANs to which the ports belong. The display is for
viewing purposes only. Figure 35 is an example of the table:
Figure 35 Static MAC Address Table Window
3. Return to the Main Menu.
Static MAC Address Table
MAC Addresses
MAC Address Port VLAN
00000C 938CDC Port 4 - Accounting1 Default VLAN
0000C0 334CE6 1 Default VLAN
00A0D2 18180B 3 Default VLAN
