Supported Platforms
152
Table 8 lists the optional expansion modules supported by the software.
Table 8 Optional Expansion Modules
Model
Number
of Ports
Type of Ports
Type of
Connector Type of
Cable
1
Maximum
Distance
2
AT-A14 1 100/1000Base-T RJ-45 Category 5 or
better twisted
pair
3
100 m (328 ft)
AT-A15/SX 1 1000Base-SX SC Multimode
fiber optic 550 m (1,804 ft)
AT-A15/LX 1 1000Base-LX SC Single-mode
fiber optic 10 km (6.2 mi)
AT-A16 2 100Base-FX VF-45 Multimode
fiber optic 2 km (1.25 mi)
AT-A17 2 100Base-FX SC Multimode
fiber optic 2 km (1.25 mi)
AT-A18 4 10/100Base-TX RJ-45 Category 3
(for 10Base-T)
or Category 5
(for 100Base-
T) or better
twisted pair 100 m (328 ft)
AT-A19 2 100Base-FX MT-RJ Multimode
fiber optic 2 km (1.25 mi)
AT-A24/SX 1 1000Base-SX MT-RJ Multimode
fiber optic 550 m (1,804 ft)
AT-A24/LX 1 1000Base-LX MT-RJ Single-mode
fiber optic 10 km (6.2 mi)
1. Multimode fiber optic cable can be either 50/125µm or 62.5/125µm cabling. Single-mode fiber optic cable must be 9/125µm
2. Maximum distance can be less depending on the duplex mode of the end node and the type of cabling used with the module.
3. Contact a qualified cabling technician for details on the IEEE specifications for Gigabit Ethernet over twisted pair cabling.
