AT-S26 Version 2.0.1 User’s Guide
87
Adding Addresses
to the Static MAC
Address Table
To add MAC addresses to the static MAC address table, perform the
following procedure:
1. Compile a list of the MAC addresses of the devices to be added to the
table.
2. From the Omega Main Menu, select MAC Address Table.
The MAC Address Table menu shown in Figure 30 is displayed.
3. Select Per port static MAC addresses.
A list of the ports on the switch is displayed.
4. Select the port where you want to add the static MAC address.
The window in Figure 36 is displayed. The window lists the static
addresses already defined for the selected port.
Figure 36 Static MAC Addresses Per Port Window
5. Select Add MAC Address.
The window in Figure 37 is displayed. You use this window to specify
the MAC address of the device you want to allow access to the port,
as well as the name of the VLAN to which the port belongs.
Figure 37 Adding a Static MAC Address Window
Add MAC Address Menu
Port 5
MAC Addresses
MAC Address VLAN MAC Address VLAN
Add MAC address
Delete MAC address
Return to Port Selection Menu ....
Add MAC Address Menu
MAC Addresses
MAC Address VLAN MAC Address VLAN
VLAN Name: Default VLAN
MAC address: Null (not configured)
Return to Add MAC Address Menu ...
