Displaying Ethernet Statistics
128
Displaying RMON Statistics for a Port
To display RMON statistics for a specific port, perform the following
procedure:
1. From the Main Menu, select Ethernet statistics.
The Receive Statistics Graph shown in Figure 51 is displayed.
2. Select Port RMON Statistics.
The Omega interface displays a list of the ports on the switch.
3. Select a port to display a graph similar to Figure 56.
4. To clear the graph, select Zero all statistics counters from the entire
system.
5. Return to the Main Menu.
Figure 56 Sample RMON Statistics Graph for a Port
Port 6
RMON Statistics Graph
64 Byte Frames: 0 |
65-127 Byte Frames: 0 |
128-255 Byte Frames: 0 |
256-511 Byte Frames: 0 |
512-1023 Byte Frames: 0 |
1024-1518 Byte Frames: 0 |
---------------------------
Zero all statistics counters on the entire system
Return to Port Statistics Graph ...
