Configuring the Ports
68
Configuring Port Parameters
This section contains the procedure for configuring the parameters for
the individual ports on a switch. Port parameters that you can change
include duplex mode, flow control, back pressure, and port speed.
To view and configure the parameter settings for the ports, perform the
following procedure:
1. From the Omega Main Menu, select Port Status and Configuration.
The Port Status window in Figure 24 on page 66 is displayed.
2. Select the port to be configured.
The Port Configuration window in Figure 25 is displayed.
Figure 25 Port Configuration Window
If you are running the Omega interface from a web browser, you can
display this window by clicking on a port in the graphical switch
image.
3. Adjust the options as desired.
Any changes to the port settings are activated immediately on the
port. The options are described below.
Port Configuration Menu
Port 1
> Enable this port
Disable (partition) this port
> Auto negotiate
Full duplex
Half duplex
Backpressure enabled (Half Duplex)
> No backpressure
Flow control (Full Duplex)
> No flow control
Global config
Discard broadcast packets
> Regular forwarding of broadcasts
Port name
Return to Port Status Menu ...
