Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Attempting to set this to any other value will result in the error message: "The error occurred
with 'Set' operation. Error: bad value".
Note - The Module ID and Port Number parameters return 'noSuchName'.
Spanning Tree Info
Displays the port's spanning tree parameters.
Enable
Enables the port.
Disable
Disables the port.
Port Mirroring
Displays port mirroring parameters and allows configuration of port mirroring state, source,
and destination.
IGMP Snooping
Displays the current state of IGMP Snooping and allows reconfiguration.
Note - Valid MIB Set values for the IGMP Report Delay parameter should range from 5 to
30. However, the current firmware version does not allow it to be set to a value greater than
10. Attempting to do so will result in the error message: "The error occurred with 'Set'
operation. Error: bad value."
Stacking Menu
From the Stacking menu, you can view basic switch information as well as stacking information.
Stacking Info
Displays information such as Hardware Version, Firmware Version, Expansion Slot, and
Role In System for all switches in the stack.
AT-8324SX
PN 613-50665 Rev A Page 56 of 257
