Port Interface Cards
This section describes the following Port Interface Cards supported in AT-View Plus Device
Manager :
AT-AR020 •
• AT-AR021
• AT-AR022
• AT-AR023
• AT-AR024
AT-AR026 •
AT-AR027 •
If one of these PICs is installed in a PIC bay of a Router (AT-AR400 series or AT-AR700 series), or
in a
Network Service Module (NSM) of a Router or Layer 3 Switch (Rapier series), it is displayed in
the PIC bay of the device in the main window. The operations available for the main device include
the ports in any of these PICs.
AT-AR020
Device Manager LEDs for AT-AR020
LED State Description
HDLC packets are being exchanged between the switch or
router and another end system device (normally another switch
or router) over any of the B (data) channels.
No packet transmission over B channel.
B Data Green
Gray
AT-AR021
